Product features
- tag reading,data writing and printing can be combined at will;
- the fastest 6 feet/second smooth printing;
- Small in appearance and powerful in function;
- Electronic tag supporting ISO18000-6C protocol;
- Strong compatibility, supporting flexible metal-resistant labels;
- Equipped with self-developed full-function RFID reading and writing function;
operating procedure
Step 1: Prepare labels and printers.
Step 2: Install printing software.
Step 3: Design a label template.
Step 4: Connect the RFID reader.
Step 5: Import print data.
Step 6: Adjust the print settings.
Step 7: print the RFID tag.
Step 8: Check the label quality.
Product parameter
| way of print | Thermal/thermal transfer printing |
| resolution ratio | 300 DPI (11.8 point/MM) |
| Maximum printing speed | 6 IPS(152.4 mm/S) |
| Maximum print width | 4.15″ (105.6 Mm) |
| Maximum print length | 78.7″ (2000Mm) |
| memory | 8MB Flash ROM, 16MB SDRAM |
| Label roll size | Width: 4.5 v (116 MM) at maximum and 0.8″(20Mm) at minimum. Outside diameter: maximum 5″(127 MM) for built-in paper bin and 8″ (203.2mm) for external paper rack; Inner diameter: 1″(25.4 MM) minimum. |
| Label thickness | 0.06 ~ 1.5mm(0.002″~0.06″), including the thickness of backing paper, supporting flexible metal-resistant labels. |
| Carbon tape size | Outer diameter (maximum): 2.75″(70 mm) Inner diameter: 1″(25.4 mm) or 0.5″(12.7Mm). Maximum width: 4.3″(110 mm) Maximum length: 300 M. |
| Paper detection mode | Reflective and penetrating double sensors |
| RFID function | Integrated high-performance UHF RFID reader/encoder, supporting and UHF EPC Gen 2/ISO 18000-6C compatible label. 1. Support the working mode of printing while reading and writing data,printing only or reading and writing only data; 2. Support reading the TID, EPC and TID+EPC data of the tag; 3. Support two-way communication between USB and network, and feedback the printer status in real time. |
| bar code | code 39,code 93,code 128,codabar,EAN-8/13/128, Interleave 2 of 5,Ucc-128,Upc A/E 2 and 5 add-on Equal one-dimensional bar code; Data Matrix,Maxicode,PDF417,QR Equal two-dimensional bar code |
| joggle/interface | RS-232 serial port,USB interface,RJ45 network port. |
| Input power supply | 24 VDC,2.0A |
| weight | 2.62 KG |
| Fuselage size | Width: 208mm,length: 310mm,height: 195 mm. |
| working environment | Temperature: 0℃ ~ 40℃,relative humidity: 5% ~ 85% without condensation. |
| Storage environment | Temperature: -40℃ ~ 60℃,relative humidity: 5% ~ 85% without condensation. |
| Optional parts | Bluetooth module,automatic paper stripper,etc |
